TEKCN TC-102 optical fiber high-accuracy light source
TEKCN TC-102 optical fiber high-accuracy light source
Optical light source (OLS) is a low-cost way to analyze and identify accurate fiber optic readings, while certifying optical fiber. Receive the ability to measure fiber optic light continuity, loss, and quality of the signal.
TEKCN TC-102 Optical Light Source is one of the latest self developed test instrument. It provide 1310/1550nm wavelength for the single mode fiber. Together with our TEKCN TC-100 optical power meter, it acts as a perfect solution for the fiber optic network work.
Highlights
1310/1550nm stable light source
Large LCD display with backlight
1310/1550nm single mode and 850/1300nm multi-mode for selecting.
3 modulation frequencies: 270Hz, 1KHz, 2KHz
Soft rubber protective cover
Low battery indicator function
Automatic shutdown function, 10 minute automatic shutdown
Can provide calibration for optical power meters and optical attenuators
Using highly stable lasers to provide high stability output power
Specification:
| Model | TC-102 |
| Output wavelength | 1310/1550nm or 850/1300nm |
| Output power | ＞-7dBm |
| Laser type | LD |
| Spectral width | 5nm |
| Short time stability | 0.01dB@5minutes |
| Long time stability | 0.1dB@24minutes |
| Connector type | PC/PC |
| FIber Type | SM MM |
| Audio carrier | 0Hz, 270Hz, 1KHz, 2KHz |
| Display information | Select wavelength, battery level, carrier state, output power, power status |
| Automatic shutdown | 10 minute automatic shutdown |
| Power supply | 3A battery |
| Continuous working hours | ＞30 hours |
| Servo stabilization circuit | have |
| Operation sound prompt | have |
| Operation temperature | -10~+60 |
| Storage temperature | -20~+70 |
| Humidity | ＜95% |
| Size | 130*63*29mm |
