TEKCN TC-100 optical fiber high-accuracy Power meter

Optical Power Meter (OPM) is a device used to measure the power in an optical signal.

Optical power meters are available as stand-alone bench or handheld instruments or combined with other test functions such as an Optical Light Source (OLS), Visual Fault Locator (VFL), or as sub-system in a larger or modular instrument. Commonly, a power meter on its own is used to measure absolute optical power, or used with a matched light source to measure loss.

Testing fiber optic connections required a fiber optic power meter and fiber optic light source. These two pieces of equipment were carried side-by-side and used together to verify a fiber optic connection was working.

Highlights

•


• Quick response, High sensitivity, large dynamic range


• Large LCD display with backlight

• Soft rubber protective cover

• Low battery indicator function

• Automatic shutdown function, 10 minute automatic shutdown

• New user automatic calibration function


• Supports 850nm, 1300nm, 1310nm, 1490nm, 1550nm, 1625nm, 6 calibration wavelengths, suitable for various testing environments

• Specification:

• Power measurement range (dBm)	-70~+10 or -50~+26
  Wavelength measurement range	800-1700
  Calibrate wavelength (nm)	850, 1300, 1310, 1490, 1550, 1625
  Probe type	InGaAs
  Measurement accuracy	＜±3% (-10dBm, 22℃)
  Operation temperature	-10~+50
  Storage temperature	-20~+70
  Power supply	3A battery
  Continuous working hours	120 hours
  Size	130*63*29mm
